Blokset Series Low Voltage Electrical Switch Power Distribution Cabinet
Switchgear with Distribution Board
Blokset is a high dependability LV distribution and motor control switchboard which is
authorized to be manufactured in our factory.
It is suitable for power distribution systems in power plants, petroleum, chemical,
metallurgy, textile, construction and other industries. As a three-phase AC frequency of
400Hz or less, rated working voltage of 690V, rated current up to 6300A, low-voltage
complete power distribution equipment for power distribution, motor centralized control,
soft start, and reactive power compensation.
| Ratedinsulationvoltage | 1000V |
| Ratedoperatingvoltage | 400/690VAC |
| Ratedfrequency | 50/60HZ |
| Ratedpulsevoltage | 12KV |
| Ratedauxiiarycircuitvoltage | 230VACmax |
| Overvoltagelevel | |
| Pollutionlevel | |
| Horizontalbusbarrating | Upto7000A |
| Verticalbusbarrating | Upto3200A |
| Horizontalbusbarrating | Ratedshort-timewithstandcurrent | 30/50/85/100KA |
| |Ratedpeakwithstandcurrent | 63/105/187/220KA |
| Verticalbusbarrating | |Ratedshort-timewithstandcurrent | 30/50/85KA |
| Ratedpeakwithstandcurrent | 63/105/187KA |
| InternalcombustionarcpersonalprotectionIEC61641 | 85KA0.4s |
| Groundingsystem | TT-IT-TNS-TNC |
| Maximuminletandoutletswitch | 6300A |
| |Maximummotorcapacity | 250kw |
Product details
The Blokset system is designed to provide a high level of reliability and safety, thus reinforcing
the protection of life and property.
Blokset offers all the essential guarantees:
compliance with international standards, notably IEC 60439-1, IEC 60529 and IEC 60947
compliance with local standards, thus meeting local legal and technical requirements a system
implementing and tested with Schneider Electric switchgear components to ensure optimum operation.
Our Service
1. Your inquiry related to our product & price will be replied within 48 hours
2. Well-trained & experienced staff are to answer all your inquiries in English
3. Working time: 8:00am ~17:30pm, Monday to Saturday. (UTC+8)
4. Customized solution & perfect after-sale service
5. Payment: we can accept T/T, L/C, Western Union.
6. For large order, engineer can be sent to your country for on-site mainternace instructions.
